Includes MMA, MIG/MAG, Syn MIG, Pulse MIG & Double Pulse welding processes. WiseFusion, WiseRoot+, MatchLog, Pipe Steel Pack Fe (25 pcs) and Pipe Stainless Pack Ss (17 pcs) software.
For steel pipe welding with Ø 200/300mm wire spools. Durable double-skin plastic casing with a strong two-motor GT04 wire feed mechanism. Built-in arc voltage measurement.
WiseFusion optimised welding function produces a very narrow and energy-dense welding arc making welding faster and heat input lower. A focused penetration area allows the welding of narrow and deep grooves. WiseFusion results in excellent penetration without risk of undercut. A narrower arc also facilitates weld pool control in position welding. WiseFusion ensures optimum arc length eliminating the need for constant parameter settings. Adaptive and automatic arc length regulation maintains the arc always within the short circuit boundaries and raises your arc-on time.
WiseRoot is an optimised short arc process for root pass welding without backing. The process is highly effective being significantly faster than stick (MMA), TIG and standard MIG/MAG short arc welding, yet producing high-quality welds. The welding of fixed pipes in any position is possible and the groove angle can be reduced by even 40%, depending on the application.
A stable and efficient arc resulting in excellent weld quality is enabled through precise real-time voltage measuring, current control and right-in-time filler metal droplet releasing. Filler metal transfer is smooth and spatter-free. WiseRoot is a MIG/MAG welding process 131, 133, 135 or 138 according to standard EN ISO 4063.
